MR10 series intelligent industrial robots

The MR10 intelligent robot polishing and deburring workstation, with its compact design and high flexibility, provides precise polishing and deburring services for industrial parts. Its fully modular concept, high-precision control system, and user-friendly human-machine interaction ensure efficient and stable operation. Expandable modules and a dual-station design further enhance work efficiency.

	Grinding		Polishing
	Filing		Miling
	Scraping		Sawing

Category: MR series

Message Contact Us

Description

Core Parameters

Polishing Precision	±0.1mm
Maximum Workpiece Weight	3KG
Maximum Workpiece Size	150×150×100mm
Robot Payload (kg)	12kg
Rated Voltage (V)	AC 380V
External Dimensions (mm)	230016002400
Rated Power (KW)	7.5
Rated Current (A)	15
Overall Weight (kg)	2800
Processing Material	Aluminum Casting
Robot Brand	Fanuc Six-Axis Articulated Robot

Product Features

1. Fully enclosed sheet metal casing to prevent dust from splashing everywhere

2. Modular design for easy maintenance

3. The robot picks up the workpiece for grinding and deburring

4. Equipped with a floating spindle, rigid spindle, pneumatic spindle, and floating file machine

5. Functions such as broken tool/sand belt detection, tool life management, and production capacity management

6. The sanding machine tensioning mechanism is hidden, with high dustproof level and long service life

7. Double-layer servo feed table, stable and high-precision positioning

8. Feed table floating function to improve grasping adaptability

Optional Configurations for Robot Grinding and Polishing

Force control grinding system Dust removal device Floating file machine Floating grinding machine

Application Scope of Robot Grinding and Polishing Equipment

Grinding, polishing, deburring, chamfering, and other
